Omron Q2A Series User Manual

Q2A 13
Braking unit
Resistor
Type Fig.
Protection
class
Dimensions (mm)
Weight
(kg)
W W1 W2 H H1 H2 D D1 t1 t2 d
CDBR-4045D 1 IP20 120 105 - 150 136 7 157 48 6 - M4 2.0
CDBR-4220D 2 IP00 175 110 7.9 294 279 7.5 200 53.5 1.6 2.5 M5 7.5
Type Fig.
Dimensions (mm)
Weight
(kg)
L H M I T G N
AX-REM00K1400-IE 1 105 27 36 94 - - - 0.2
AX-REM00K2200-IE
AX-REM00K4075-IE 200 189 0.425
AX-REM00K5120-IE 260 249 0.58
AX-REM00K9070-IE 2 200 61 100 74.5 216 40 230 1.41
AX-REM01K9070-IE 3 365 73 105 350 70 - - 4
AX-REM03K5035-IE 4 365 100 240 350 210 8
AX-REM19K0020-IE 5 206 350 140 190 50 8.1
AX-REM19K0030-IE
AX-REM38K0012-IE 306 290 14.5
W1
4-d
H
H1
D
D1
t1
W
H2
W Max. W2Max. W2
W1
D
t1D1
t2
4-d
H
H1
H2
Fig 2Fig 1
168
13
45
20
182
AX-REM00K15xxx
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
