Items to Check after Unpacking
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
Items to Check after Unpacking
After unpacking, check the following items.
 Is this the model you ordered?
 Was there any damage sustained during shipment?
Accessories of This Product
Safety Precautions document × 1 copy
 Connectors, mounting screws, mounting brackets, and other accessories other than those in
the table below are not supplied. They must be prepared by the customer.
The safety bypass connector is required when the safety function is not used. To use the
safety function, provide a Safety I/O Signal Connector separately.
 If any item is missing or a problem is found such as Servo Drive damage, contact the
OMRON dealer or sales office where you purchased your product.
Specifications
Connector for main
circuit power supply
terminals and control
circuit power supply
terminals
Connector for External
Regeneration Resistor
connection terminals and
motor connection
terminals
Safety
bypass
connector
Mounting
Brackets
Single-
phase
100 VAC
50 W
Included
Included
−
100 W
200 W
400 W
Single-
phase/3-
phase
200 VAC
100 W
200 W
400 W
750 W
1 kW
1.5 kW
3-phase
200 VAC
2 kW
Included
3 kW
−
5 kW
7.5 kW
15 kW
−
3-phase
400 VAC
600 W
Included
1 kW
1.5 kW
2 kW
Included
3 kW
−
5 kW
7.5 kW
15 kW −
