1-3 Names and Functions
1
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
Features and System Configuration
1-3 Names and Functions
Servo Drive Part Names
Display
Operation area
USB connector (CN7)
Expansion connector (CN3)
Analog monitor connector (CN5)
Motor connection
terminals (U, V and W)
Control circuit
power supply terminals
(L1C and L2C)
Main circuit
power supply terminals
(L1, L2, and L3)
External Regeneration
Resistor connection
terminals (B1, B2, and B3)
Protective ground terminals
Control I/O connector (CN1)
Safety connector (CN8)
External encoder connector (CN4
Encoder connector (CN2)
Charge lamp
