Omron R88M-K Series - Encoder Dividing Function

6-14
6-5 Encoder Dividing Function
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
6
Applied Functions
6-5 Encoder Dividing Function
Outline of Operation
 The number of output pulses from the drive can be adjusted.
 You can set the number of pulses per motor rotation in the range of 1 to (the number of encoder
resolution pulses).
 This function is used in the following cases:
- When you use a controller with a low response frequency
- When you want to set the pulse rate corresponding to a certain value
Example: Set the encoder dividing ratio to 2,000 (pulses/rotation) for when the
resolution is set to 5 μm/pulse on mechanical systems that travel 10 mm per
motor rotation.
Parameters Requiring Settings
Parameter
number
Parameter name Explanation Reference
Pn011
Encoder Dividing
Numerator
Set the number of phase-A and phase-B output
pulses, respectively per motor rotation.
P.8-6
Pn012
Encoder Output
Direction Switching
Selection
Select the phase B logic for pulse regeneration
output and the output source. P.8-6
Pn503
Encoder Dividing
Denominator
Set the denominator when the number of pulses
per motor rotation in pulse regeneration is not an
integer.
P.8-47
Pn533
Pulse Regeneration
Output Limit Setting
Set whether to enable or disable the detection of
Alarm 28.0 "pulse regeneration error."
0: Disabled, 1: Enabled
P.8-59
Pn620
External Encoder
Phase-Z Setting
Set the external encoder phase-Z output width.
P.8-63
Pn622
90° Phase Difference
Output External
Encoder Pulse Output
Method Selection
Select the regeneration method of pulse outputs A
and B when a 90° phase difference output type
external encoder is used.
0: Without signal regeneration.
1: With signal regeneration for phase-A and
phase-B. Without signal regeneration for phase-Z.
P.8-63
