12-2 Parameter List
Some parameters are enabled by turning the power supply OFF and then ON again. (Those
parameters are indicated in the table.) After changing these parameters, turn OFF the power
supply, confirm that the power supply indicator has gone OFF, and then turn ON the power supply
again.
Do not change the parameters marked "Reserved". Do not change the settings marked
"Reserved".
Basic Setting Parameters
Pn number
Parameter
name
Description
Default
setting
Unit
Setting
range
Power
supply
OFF to
ON
000
Rotation
Direction
Switching
Set the relation between the command
direction and the motor rotation direction.
1 − 0 or 1 Yes
0
A forward direction command sets the
direction to CW as viewed from the shaft end
1
A forward direction command sets the
direction to CCW as viewed from the shaft
end
001
Control Mode
Selection
Select the Servo Drive control mode.
0 − 0 to 6 Yes
0 Position control (pulse train command)
1 Speed control (analog command)
2 Torque control (analog command)
3
No. 1: Position control
No. 2: Speed control
4
No. 1: Position control
No. 2: Torque control
5
No. 1: Speed control
No. 2: Torque control
6 Fully-closed control
002
Realtime
Autotuning
Mode Selection
Set the operation mode for realtime autotuning.
1 − 0 to 6 −
0 Disabled
1 Emphasizes stability
2 Emphasizes positioning
3
If there is an unbalanced load like in a
vertical axis.
4 Used when friction is large.
5
Used when there is an unbalanced load,
such as a vertical axis, and friction is large.
6
Used to customize the Realtime
Autotuning Mode.
003
Realtime
Autotuning Machine
Rigidity Setting
Set the machine rigidity for executing
realtime autotuning.
See
Note 1
− 0 to 31 −
004 Inertia Ratio
Set the load inertia as a percentage of the
motor rotor inertia.
250 %
0 to
10,000
−
To Next Page
