Omron R88M-K Series User Manual

2-38
2-4 External and Mounting Dimensions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
3-phase 400 VAC: R88D-KT20F (2 kW)
Wall Mounting
External dimensions Mounting dimensions
Front Mounting (Using Front Mounting Brackets)
External dimensions Mounting dimensions
* Rectangular hole dimensions are reference values.
φ5.2
R2.6
R2.6
φ5.2
193.5 1.5
94
85
50
17.5
42.5
5.2
5.2
5.2 5.2
50
17.5
168 188 198
70
26.5
188 168
50
94
25
6-M4
Rectangular
hole
φ5.2
R2.6
R2.6
φ5.2
2.5
193.5
30.7
94
85
50
5.2
17.5
42.5
168 188 198
5.2
17.5
50
5.2
2.5
5.2
70
25
188
5027.5
6-M4
(176)*
(96)*
6
