S82J
S82J
10
Input
AC(L)
AC(N)
Fuse (5 A)
Noise filter
Control circuit
Overload
detection
circuit
Photocoupler
Detector
+V
–V
DC Output
S82J-10024jj (100
W
, 24-V Output)
Rectifier Inrush current
protection
circuit
Smoothing
circuit
Rectifier and
smoothing
circuit
Photocoupler
Overload
detection
circuit
+V
–V
DC OutputInput
AC (L)
AC (N)
Fuse (8 A)
Noise filter
Inrush current
protection circuit
Rectifier
Control circuit
Overcurrent
detector
Rectifier
and
smoothing
circuit
Detector
Photocoupler
S82J-15024jj (150 W)
100 or 200 V
(selected au-
tomatically)
S82J-30024j
(300 W)
Parallel operation selector
100/200 V (selectable)
Note: Short-circuit the input voltage selector
terminals
if the input is 100 to 120 V
AC.
Keep the terminals open if the input is
200 to 230 VAC.
Fuse
(10 A)
Noise filter
Inrush current
protection circuit
Rectifier
and
smoothing
circuit
Detector
Photocoupler
Overvoltage
detector
Photocoupler
Control
circuit
Overcurrent
detector
Rectifier and
smoothing circuit
DC Output
Input
