Omron S82J Series User Manual

S82J
S82J
11
S82J-60024j (600 W)
Parallel operation selector
100/200 V (selectable)
Note: Short-circuit the input voltage selector
terminals if the input is 100 to 120 VAC.
Keep
the terminals open if the input is 200
to 230 VAC.
Fuse
20 A
Noise filter
Inrush current
protection circuit
Rectifier
and
smoothing
circuit
Detector
Photocoupler
Photocoupler
Control
circuit
Overcurrent
detector
Fan
Overheat
detector
Overvoltage
detector
Rectifier and
smoothing circuit
DC Output
Input

Omron S82J Series Specifications

General

Brand	Omron
Model	S82J Series
Category	Power Supply
Language	English
