Omron S82K Series User Manual

New S82K
New S82K
18
S82K-030
jj
(30 W)
S82K-05024 (50 W)
4
(sliding 7 max.)
M3.5 with square washer
Four, M4 or 4.5-dia. mounting holes
60
80
L
Four, 4.5 dia.
Mounting Holes
Note:
If more than one Power Supply is
installed in a row, keep a distance of
20 mm min. (L = 20 mm min.) between
each adjacent Power Supply.
35
S82K-
j
09024 (90 W)
S82K-
j
10024 (100 W)
60
135
L
Four, M4 or 4.5-dia. mounting holes
58.1
75
4
(sliding 7 max.)
M3.5 with square washer
Short bar
M3.5 terminal screw
60
!
0.2
145
135
!
0.2
Four, 4.5 dia.
91
35
7.5
5
Mounting Holes
Note:
If more than one Power Supply is
installed in a row, keep a distance of
20 mm min. (L = 20 mm min.) between
each adjacent Power Supply.
45
8.39.8

Omron S82K Series Specifications

General

Category	Power Supply
Type	Switching Power Supply
Input Voltage	100 to 240 VAC
Output Voltage	5 VDC, 12 VDC, 24 VDC
Operating Temperature Range	-10°C to +60°C
Mounting Type	DIN Rail
Safety Standards	UL508
Protection Features	Overvoltage, Short Circuit
Cooling Method	Convection
Dimensions	Varies depending on model
