New S82K
New S82K
19
S82K-
j
24024
j
M3.5 with square washer
Short bar
M3.5 terminal screw
Mounting Holes
Note:
If more than one Power Supply is installed in a row, keep a distance of
20 mm min. (L = 20 mm min.) between each adjacent Power Supply.
Four, M4 or 4.5-dia. mounting holes
130
112.8
Four, 4.5 dia.
100
115
!
0.2
4
(sliding 8 max.)
9.8
8.3
35
7.8
27.5
270
115
!
0.2
4.2
138
280
270
!
0.2
L
Accessories
Mounting Track (Order Separately)
PFP-100N/PFP-50N
4.5
15 25 25 25 25
10 10
1,000 (500)
(see note)
7.3
!
0.15
35
!
0.3
27
!
0.15
1
4.5
15 25 25 25 25 15
10 10
1,000
35
!
0.3
27 24
16
29.2
11.5
PFP-100N2
15 (5)
(see note)
Note:
The values shown in parentheses are for the
PFP-50N.
Noise Filter (Order Separately)
S82Y-JF3-N for 3- to 50-W Models
S82Y-JF6-N for 90- and 100-W Models
39
!
0.5
16 max.
Amax.
B
!
1
Two, 4.8 dia.
(Mounting
holes)
D
!
1
6.5
4
Six, M4
6.5
C
!
0.5
16 max.
4
Nameplate
47
!
1
Model A B C D
S82Y-JF3-N 107 75 90 26
S82Y-JF6-N 117 85 100 30

Omron S82K Series Specifications

General

Category	Power Supply
Type	Switching Power Supply
Input Voltage	100 to 240 VAC
Output Voltage	5 VDC, 12 VDC, 24 VDC
Operating Temperature Range	-10°C to +60°C
Mounting Type	DIN Rail
Safety Standards	UL508
Protection Features	Overvoltage, Short Circuit
Cooling Method	Convection
Dimensions	Varies depending on model
