Omron S82K Series

New S82K
New S82K
7
3- to 240-W models without PFC
Item
Single output Dual
outputs
Single output
3W 7.5 W 7.5 W 15 W 30 W 50 W 90 W 100 W 240 W
Output
(see
note 2)
Voltage adjustment
range
!
10% (V.ADJ)
Not pos-
sible
(see note
3)
!
10% (V.ADJ); --10% to 15% for S82K-03012/-03024/-05024
Ripple (see note 1)
2% (p-p) max.
Input variation
influence
0.5 % max. (at 85 to 264 VAC input, 100% load) 0.5%max.(at85to
132 VAC/170 to
264 VAC input, 100%
load)
0.5 %
max. (at
85 to
132 VAC/
170 to
253 VAC
input,
100%
load)
Load va riation
influence
1.5% max.
(0 to 100% load)
+V: 1.5%
max.
-V: 3 %
max.
(0 to
100%
load)
1.5% max.
(0 to 100% load)
1.5%
max.
(10 to
100%
load)
Temperature
variation influence
(see note 1)
0.05%/
"
Cmax.
Start up time
100 ms max. (up to 90% of output voltage at rated input and
output)
200 ms max. 300 ms
max.
Hold time
(see note 1)
20 ms min.
Addi-
tional
function
Overload protection
105% to 160% of
rated load current,
inverted L drop,
automatic reset
(see note 4)
105% to
250% of
rated
load cur-
rent, in-
verted L
drop, au-
tomatic
reset
105% to 160% of rated load
current, inverted L drop,
automatic reset
(30-W , 50-W models:
inverted L drop, intermittent,
automatic reset)
101% to
111% of
rated
load cur-
rent, in-
verted L
drop, au-
tomatic
reset
(see note
5)
105% to 160% of
rated load current,
inverted L drop,
automatic reset
Overvoltage
protection (see note
6)
No S82K-
24024T
model
only
Undervoltage alarm
indicator (DC LOW
indicator)
Yes (color: red) S82K-
24024T
model
only
Undervoltage alarm
output (DC LOW
output)
No Yes S82K-
24024T
model
only
Parallel operation
Impossible Possible (2 units
max.)
Note:
1. Defined with a 100% load and the rated input voltage (100 or 200 VAC).
2. The output specification is defined at the power supply output terminals.
3. The settings for the output voltage must be within the following range:
+V:
!
1% of the rated value
-- V:
!
5% of the rated value
4. When using the 7.5-W single-output models within the input voltage range between 90 and 110 VDC, the protection function will
operate at a current of 95% to 160% of the rated load current.
5. When the ambient temperature exceeds 25
"
C, the protection function will operate at a current of 92% to 1 11% of the rated load
current.
6. Circuit-breaker type. To reset, turn the input power supply OFF, then after 1 min has elapsed, turn the input power supply ON again.
