Omron S82K Series User Manual

New S82K
New S82K
8
3- to 240-W models without PFC
Item
Single output Dual
outputs
Single output
3W 7.5 W 7.5 W 15 W 30 W 50 W 90 W 100 W 240 W
Other
Ambient
temperature
Operating: See the derating curve in the
Engineering Data
section
(no condensation or icing)
Storage: --25
"
Cto65
"
C (no condensation or icing)
Ambient humidity
Operating: 25% to 85%
Storage: 25% to 90%
Dielectric strength
3,000 VAC at 50/60 Hz for 1 min (between all inputs and outputs)
2,000 VAC at 50/60 Hz for 1 min (between all inputs and GR terminal)
1,000 VAC at 50/60 Hz for 1 min (between all outputs and GR terminal)
Alarm current: 10 mA (3- to 7.5-W models) 20 mA (15- to 100-W models) 25 mA (240-W models)
Insulation
resistance
100 M
#
min. at 500 VDC (between all outputs and all inputs/GR terminal)
Vibration
resistance
Malfunction: 10 to 55 Hz, 0.375-mm single amplitude for 2 hrs each in X, Y, and
Z directions
Malfunction: 10
to 55 Hz,
0.15-mm single
amplitude for 2
hrs each in X, Y,
and Z directions
Shock resistance
Malfunction: 300 m/s
2
, 3 times each in
!
X,
!
Y, and
!
Z directions
Screw tightening
torque
0.74 N
S
m max. (see note 2)
Output indicator
Yes (green)
Electromagnetic
interference
(see note 1)
Conforms to FCC class B Conforms to FCC class A
EMC
(see note 3)
3 to 100-W Models
(EMI): EN50081-1
Emission Enclosure: EN55022 class B (equivalent to EN55011 class B)
Emission AC Mains: EN55022 class B (equivalent to EN55011 class B)
Emission Output Ports: EN55022 class A (with a recommended optional filter) (see note 3)
240-W Models
(EMI): EN50081-2
Emission Enclosure: EN55011 class A
Emission AC Mains: EN55011 class A
Common to All Models
(EMS): EN50082-2
Immunity ESD: EN61000-4-2: 4-kV contact discharge (level 2)
8-kV air discharge (level 3)
Immunity Burst: EN61000-4-4: 2-kV power-line (level 3)
2-kV output line (level 4)
Immunity Surge: EN61000-4-5: between 2-kV lines (except for 240-W models)
between 4-kV line and FG (except for 240-W models)
Approved
standards
Class 2 (UL 1310)/Class 2 (CSA C22.2 No. 950) (see notes 4 and 5)
UL 508 (Listing)/1950
CSA C22.2 No.14/No.950, EN50178 (VDE0160), EN60950
Conforms to VDE0106/P100
UL 508
(Listing)/1012
CSA C22.2
No.14, CSA E.B.
1402C, EN50178
(VDE0160),
EN60950
Conforms to
VDE106/P100
Weight
150 g max. 260 g
max.
380 g
max.
400 g
max.
600 g max. 1,800 g max.
Note:
1. Defined with a 100% load and the rated input voltage (100 or 200 VAC).
2. Do not press down on the terminal block with a force exceeding 75 N while tightening the terminals.
3. To ensure the emission ratings, a noise filter should be used on the output lines at the closest point.
(3- to 50-W models: S82Y-JF3-N, 90- and 100-W models: S82Y-JF6-N)
4. Models other than dual output models satisfy the Class-2 requirements.
5. To meet Class-2 requirements with the 100-W model, either a fuse or circuit breaker that is UL listed or CSA certified, and rated at
4.2 A max. should be wired in series with the load to be connected to the power supply. Only then can the power supply output be
considered as meeting Class 2.

Omron S82K Series Specifications

General

Category	Power Supply
Type	Switching Power Supply
Input Voltage	100 to 240 VAC
Output Voltage	5 VDC, 12 VDC, 24 VDC
Operating Temperature Range	-10°C to +60°C
Mounting Type	DIN Rail
Safety Standards	UL508
Protection Features	Overvoltage, Short Circuit
Cooling Method	Convection
Dimensions	Varies depending on model
