S8JX
28
S8JX-G
S8JX-P
Common Precautions
35
50
4.5
R2
R2.25
R0.5
188
178±0.5
3
4.5 dia.
Thickness = 2
B
A
A
B
Mounting Bracket C
S82Y-JX15B
Screws used
A: Accessories (2 locations)
Be sure to use the accessory screws.
Mounting screw tightening torque
(recommended): 0.49 N
· m
B: M4 (2 locations)
Method of Mounting
119
110±0.5
4.5
25
45
45.6
54
5 dia.
Thickness = 1.6
B
B
A
A
Mounting Bracket D
S82Y-JX15F
Screws used
A: Accessories (2 locations)
Be sure to use the accessory screws
Mounting screw tightening torque
(recommended): 0.49 N · m
B: M4 (2 locations)
Method of Mounting
112±0.5
3.5 dia.
Thickness = 2
28
40
3.5
R0.5
R2
R1.75
124
6.5
B
B
A
A
Mounting Bracket E
S82Y-JX03B
Screws used
A: Accessories (2 locations)
Be sure to use the accessory screws.
Mounting screw tightening torque
(recommended): 0.49 N · m
B: M3 (2 locations)
Method of Mounting
