28 Switch Mode Power Supply S8VM
Mounting Bracket E (Horizontal Bottom Mounting for 300-W Models)
Mounting Bracket F (Front Mounting for 300-W Models)
6
202
8
215
52
84
16
Three, 4.5 dia.
B
A
A
A
A
B
B
S82Y-VM30S
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed screws in four places.)
B: M4
(three places)
Mounting screw tightening torque (recom-
mended): 1.27 N·m
A
A
A
A
B
B
B
60
4.5
Two, 4.5 dia.
48
67
13.5
102.3 105
243 max.
215.3
5
S
82Y-VM30F
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed screws in four places.)
B: M4
(three places)
Mounting screw tightening torque (recom-
mended): 1.27 N·m
