Omron S8VM - Page 29

Switch Mode Power Supply S8VM 29
Mounting Bracket G (DIN Rail Mounting for 300-W Models)
Mounting Bracket H (Bottom Mounting for 600-W Models)
Mounting Bracket I (Horizontal Bottom Mounting for 600-W Models)
6.4
60
102.3
67
9.5
243 max.
215.3
A
A
A
A
S
82Y-VM30D
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed screws in
four places.)
Mounting screw tightening torque
(recommended): 1.27 N·m
B
A
A
A
A
B
B
6
202
8
215
100
72
Three, 4.5 dia.
S82Y-VM60B
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed
screws in four places.)
B: M4
(three places)
Mounting screw tightening
torque (recommended):
1.27 N·m
6
202
8
215
84
52
16
Three, 4.5 dia.
B
A
A
A
A
B
B
S82Y-VM60S
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed
screws in four places.)
B: M4
(three places)
Mounting screw tightening
torque (recommended):
1.27 N·m
