30 Switch Mode Power Supply S8VM
Mounting Bracket J (Front Mounting for 600-W Models)
Mounting Bracket K (DIN Rail Mounting for 600-W Models)
Two, 4.5 dia.
102.3
82
98
105
13.5
4.5
5
105
257 max.
222.3
A
A
A
A
B
B
B
S82Y-VM60F
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed screws in
four places.)
B: M4
(three places)
Mounting screw tightening torque
(recommended): 1.27 N·m
A
A
A
A
S82Y-VM60D
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed screws in
four places.)
Mounting screw tightening torque
(recommended): 1.27 N·m
257 max.
222.3
9.5
6.4
102.3
98
105
