Switch Mode Power Supply S8VM 31
■ Other Items Sold Separately
Undervoltage Alarm Output Wiring Cable
■ DIN Rail (Order Separately)
Note: All units are in millimeters unless otherwise indicated.
Mounting Rail (Material: Aluminum)
Mounting Rail (Material: Aluminum)
Name Model
Undervoltage Alarm Output Wiring Cable S82Y-VM10H
Terminal and Housing S82Y-VM30C
Replacement Fan Unit for 300-W Models S82Y-VM30FAN
Replacement Fan Unit for 600-W Models S82Y-VM60FAN
Replacement Fan Unit for a 1,500-W Model S82Y-VM15FAN
3,000±50
: AWG24
XHP-3 (Manufactured by JST)
to
:
S82Y-VM60D (for S8VM-05024A@/05024P@/10024A@/10024P@/15024A@/15024P@ Only)
Using the Undervoltage Alarm
Output Wiring Cable
1,000 (500) *
15(5) *
*Values in parentheses
are for the PFP-50N.
PFP-100N
PFP-50N
4.5
15 25 25
10 10
25 25
35
±
0.3
7.3
±
0.15
27
±
0.15
1
PFP-100N2
4.5
15 25 25
10 10
1,000
25 25 15
11.5
29.2242735
±
0.3
16
