Omron SPINOGY 3G3MX2 - Page 14

14
04 Commissioning
Items
Contents
(1) POWER LED
Turns ON (Green) while the inverter is powered up.
(2) ALARM LED
Turns ON (Red) when the inverter trips.
(3) Programm LED
· Turns ON (Green) when the display shows
changeable parameter.
· Blinks when there is a mismatch in setting.
(4) RUN LED
Turns ON (Green) when the inverter is driving the
motor.
(5) Monitor LED [Hz]
Turns ON (Green) when the displayed data is current
related.
(6) Monitor LED [A]
Turns ON (Green) when the displayed data is current
related.
(7) RUN command LED
Turns ON (Green) when a Run command is set to
the operator. (Run key is effective.)
(8) 7-seg LED
Shows each parameter, monitors etc.
(9) RUN key
Makes inverter run.
(10) STOP/RESET key
· Makes inverter decelerates to a stop.
· Reset the inverter when it is in trip situation.
(11) CYCLE key
· Go to the top of next function group, when a
function mode is shown.
· Cancel the setting and return to the function code,
when a data is shown.
· Moves the cursor to a digit left, when it is in digit-
to-digit setting mode.
· Pressing for 1 second leads to display data of
d001, regardless of current display.
(12) Up key
(13) Down key
· Increase or decrease the data.
· Pressing the both keys at the same time gives you
the digit-to-digit edit.
(14) SET key
Go to the data display mode when a function code is
shown.
· Stores the data and go back to show the function
code, when data is shown.
· Moves the cursor to a digit right, when it is in digit-
to-digit display mode.
(15) USB connector
Connect USB connector (mini-B) for using PC
communication.
(16) RJ45 connector
Connect RJ45 jack for remote operator.
