01 General remarks
01 General remarks
01.1 Notice
This document is only a quick start guide for the MX2 frequency inverter, and therefore it has no claim to be
complete. The document is only intended for the proper commissioning of the frequency inverter. The safety
instructions can be found in the MX2 operating manual.
01.2 Limitation of liability
SPINOGY doesn’t assume liability for personal injuries, material damages, damages caused to the device and
consequential damages caused by failure to follow this quick start guide, improper use of the device, repairs or
any other actions done by non-qualified workers on the device or damages on this unit occur or occurred by
using unauthorized non-approved spare parts.
01.3 Product name
This quick start guide is intended for the spindles of the following type:
Product name:
3G3MX2
01.4 Labeling of the frequency inverter MX2
The Omron MX2 inverters are equipped with product labels on the right side of the housing, as pictured below.
It must be ensured that the technical data on the label is compatible to the network supply and the safety
requirements of the application.
