5
02 Technical description
02 Technical description
02.1 Product overview
Input
Type
HD-Mode
Rated
current (A)
Motor output
(kW)
Rated
current (A)
Motor output
(kW)
1 x 230 V
MX2-AB007
6,0
1,1
5,0
0,75
MX2-AB015
9,6
2,2
8,0
1,5
MX2-AB022
12,0
3,0
11,0
2,2
3 x 400 V
MX2-A4004
2,1
0,75
1,8
0,4
MX2-A4007
4,1
1,5
3,4
0,75
MX2-A4015
5,4
2,2
4,8
1,5
MX2-A4022
6,9
3,0
5,5
2,2
MX2-A4030
8,8
4,0
7,2
3,0
MX2-A4040
11,1
5,5
9,2
4,0
MX2-A4055
17,5
7,5
14,8
5,5
MX2-A4075
23,0
11,0
18,0
7,5
02.2 Technical data
Item
General specifications
Protective housing
IP20
Control method
Sinusoidal Pulse Width Modulation (PWM) control
Carrier frequency
2 kHz to 15 kHz (derating required depending on the model)
Output frequency range
0,1 to 1000 Hz
Frequency accuracy
Digital command: 0.01% of the maximum frequency
Analog command: 0.2% of the maximum frequency (25°C ±10°C)
Frequency setting
resolution
Digital: 0,01 Hz; Analog: max. Frequenz/400
Volt./Freq. characteristic
V/f control (constant torque, reduced torque, free-V/F): base freq. 30 Hz to1000
Hz adjustable
Sensorless vector control, Closed loop control with motor encoder feedback:
base freq. 30 Hz ~ 400 Hz adjustable
Overload capacity
Dual rating: HD (heavy duty) : 60 s @ 150 %
ND (Normal duty) : 60 s @120 %
Acceleration/deceleration
time
0.01 to 3600 seconds, linear and S-curve accel/decel,2. Einstellung für second
accel/decel setting available
Starting torque
200 % @ 0,5 Hz (sensorless vector control)
Input signal
Freq. setting
Operator panel
Up and Down keys / Value settings
External signal
0 to 10 VDC (input impedance 10 k
Ohms), 4 to 20 mA (input impedance
100 Ohms), Potentiometer (1 k to 2 k
Ohms, 2 W)
Via network
RS485 ModBus RTU, other network
option
FWD/REV run
Operator panel
Run/Stop (Forward/Reverse run
change by command)
External signal
Forward run/stop, Reverse run/stop
Via network
RS485 ModBus RTU, other network
option
Intelligent input terminal
Seven terminals, sink/source
