Omron STC-HD213DV

No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
’
s Guide
31/94
Page 5
1) RES / FPS
Sets the video format and frame rate for video output from below twelve output formats for DVI output
models, eleven output format for SDI output models.
Please selects the video output format and frame rate to match specifications of monitor or capture devices.
If the monitor or capture devices does NOT support default setting, please selects video output format and
frame rate with PC communication.
Setting selection: 1080p60 / 1080p59.94 / 1080p50 / 1080p30 / 1080p25 / 1080i60 / 1080i59.94 /
1080i50 / 720p60 / 720p59.94 / 720p50 / AUTO
* AUTO is only available for DVI output models.
When selecting “AUTO”, camera checks supported resolution and frequency of monitor
then camera switches to monitor supported maximum resolution and frequency
automatically.
Default: AUTO (DVI output models)
1080i59.94 (SDI output models)
2) OSD SIZE
Sets the character size of OSD (Default: LARGE).
a) LARGE
OSD display with large size of character.
b) SMALL
OSD display with small size of character.
3) PROFILE
Preset data (from PRESET0 to PRESET7) can be apply to camera. (Default: PRESET0)
PAGE 1 2 3 4 5 6
RES / FPS AUTO
OSD SIZE LARGE
PROFILES PRESET0
PATTERNS OFF
IMAGE OUTPUT STANDARD
OUTPUT RANGE FULL
