4-19
n09
Multi-function Output Selection 1 (MA and MB)
Setting range 0 to 10 Factory setting 1 (Operation in
progress)
n10
Multi-function Output Selection 2 (PA)
Setting range 0 to 10 Factory setting 0 (Fault occur-
rence)
One of the following values can be specified for the multi-function contact output (MA
and MB) and multi-function photocoupler output (PA).
Value Description
0 Fault occurrence (when ON)
1 Operation in progress (with RUN command input or inverter output)
2 Frequency detection (see note 1)
3 Idling
4 Frequency detection (output frequency is same or higher than frequency
detection level determined with constant set in n53.)
5 Frequency detection (output frequency is same or lower than frequency
detection level determined with constant set in n53.)
6 Over-torque being monitored
7 Base block in progress
8 UV in progress (undervoltage being monitored)
9 Speed search in progress
10 Run mode (see note 2)
Note 1. The output is turned ON when the difference between the reference frequency
and the output frequency falls within 2 Hz. The output is turned OFF when the
difference is ±4 Hz or more.
Note 2. The output is turned ON when LOCAL is selected with the Digital Operator.
Note 3. Use “operation in progress” (set value: 1) or “idling“ (set value: 3) setting for the
timing for stopping the motor using a brake. To specify a precise stop timing, set
“frequency detection 1” (set value: 4) or “frequency detection 2” (set value: 5),
and set the frequency detection level (n53).
Preparing for Operation Chapter 4
