Omron SYSDRIVE 3G3FV CE Series User Manual

2-16
D Main Circuit Terminals
Voltage class 200-V class 400-V class
Model 3G3HV- AB004 to AB037 A4004 to A4150 B4185 to B416K
Maximum
applied motor
capacity
0.4 to 3.7 kW 0.4 to 15 kW 18.5 to 160 kW
L (R)
Power supply input ---
N (S)
terminals, single phase, 200
to 230 VAC, 50/60 Hz
L1 (R)
--- Power supply input Power supply input
L2 (S)
terminals, 3-phase, 380 to terminals, 3-phase, 380 to
L3 (T)
460 VAC, 50/60 Hz 460 VAC, 50/60 Hz
L11 (R1)
---
L21 (S1)
L31 (T1)
T1 (U)
Motor output terminals, Motor output terminals, 3-phase, 380 to 460 VAC
T2 (V)
3-phase, 200 to 230 VAC (correspond to input voltage)
T3 (W)
(correspond to input voltage)
B1
Braking Resistor Unit Braking Resistor Unit ---
B2
connection terminals connection terminals
–
DC reactor connection DC reactor connection ---
1
+
terminal ( 1- 2)
+ +
terminal ( 1- 2)
+ +
2
+
DC power supply input
terminal ( 1- )
+
–
DC power supply input
terminal ( 1- )
+
–
Ground the terminal at a
resistance of less than
100 Ω.
Ground the terminal at a resistance of less than 10 Ω.
Installation Chapter 2
