Inverter model
3G3SV-
-E
B2037B2022B2015B2007B2004B20023-phaseInverter model
3G3SV-
-E
BB037BB022BB015BB007BB004BB002Single-phase
Power supply Rated input voltage and fre-
quency
3-phase: 200/208/220 V, 50 Hz
200/208/220/230 V, 60 Hz
Single-phase: 200/208/220/240 V, 50 Hz
200/208/220/230 V, 60 Hz
Allowable voltage fluctuation
10%
Allowable frequency fluctua-
tion
5%
Control char-
Control method Sine wave PWM
acteristics
Frequency control range 0.1 to 400 Hz
Frequency accuracy Digital command: 0.01% +14
to 104
F, -- 10
to 40
C
Analog command: 0.1% 77
18
F, 25
10
C
Frequency resolution Digital operator reference: 0.1 Hz.
Analog reference: 0.06 Hz/60 Hz
Output frequency resolution 0.1 Hz
Overload capacity 150% rated output current for one minute
Frequency setting signal 0to10VDC(20k
), 4-20 mA (250
)
Accel/decel time 0.1 to 600 sec (accel/decel time setting independently)
Braking torque Approx. 20% (up to 150% possible with optional braking
resistor externally mounted)
V/f characteristic Possible to set any program of V/f pattern
Stall prevention level Possible to set operating current
Protective
Instantaneous overcurrent Motor coasts to a stop at approx. 200% rated current.
functions
Overload Motor coasts to a stop for 1 minute at 150% rated output
current
Motor overload protection Electronic thermal overload relay
Overvoltage Motor coasts to a stop if converter output voltage exceeds
410 V.
Undervoltage Motor coasts to a stop if the converter output voltage of a
3-phase model drops to 210 V or below and that of a
single-phase model drops to 170 V or below.
Ground fault Provided by electronic circuit.
Momentary power loss Immediately stops if 15 ms or more momentary power
loss. Resumes operating after a power loss period of
approximately 2 s if the input is 1.5 kW or more and
approximately 1 s if the input is 0.75 kW or less in a certain
mode.
Heat sink fin overheat Protected by thermistor
Power charge indication Charge lamp stays ON until bus voltage drops below 50 V.
Section 1-8
