Omron SYSMAC CP2E-N D Series User Manual

Appendices
A-86
CP2E CPU Unit Software User’s Manual(W614)
A540 00 Pulse Output 0 Reset
Bit
The pulse output 0 PV (contained in
A276 and A277) will be cleared when
this bit is turned ON.
OFF to ON: Cleared Retained Cleared --- A276 and
A277
08 Pulse Output 0 CW
Limit Input Signal Flag
This is the CW limit input signal for
pulse output 0, which is used in the
origin search. To use this signal, write
the input from the actual sensor as an
input condition in the ladder program
and output the result to this flag.
--- Retained Cleared ---
09 Pulse Output 0 CCW
Limit Input Signal Flag
This is the CCW limit input signal for
pulse output 0, which is used in the
origin search. To use this signal, write
the input from the actual sensor as an
input condition in the ladder program
and output the result to this flag.
--- Retained Cleared ---
10 Pulse Output 0
Positioning
Completed Signal
This is the positioning completed input
signal used in the origin search for
pulse output 0. The input signal from
the servo driver is output to this bit
from the ladder program to enable
using the signal.
--- Retained Cleared ---
A541 00 Pulse Output 1 Reset
Bit
The pulse output 1 PV (contained in
A278 and A279) will be cleared when
this bit is turned ON.
OFF to ON: Cleared Retained Cleared --- A278 and
A279
08 Pulse Output 1 CW
Limit Input Signal Flag
This is the CW limit input signal for
pulse output 1, which is used in the
origin search. To use this signal, write
the input from the actual sensor as an
input condition in the ladder program
and output the result to this flag.
--- Retained Cleared ---
09 Pulse Output 1 CCW
Limit Input Signal Flag
This is the CCW limit input signal for
pulse output 1, which is used in the
origin search. To use this signal, write
the input from the actual sensor as an
input condition in the ladder program
and output the result to this flag.
--- Retained Cleared ---
10 Pulse Output 1
Positioning
Completed Signal
This is the positioning completed input
signal used in the origin search for
pulse output 1. The input signal from
the servo driver is output to this bit
from the ladder program to enable
using the signal.
--- Retained Cleared ---
A542 00 Pulse Output 2 Reset
Bit
The pulse output 2 PV (contained in
A52 and A53) will be cleared when
this bit is turned ON.
OFF to ON: Cleared
Retained Cleared --- A52 and
A53
08 Pulse Output 2 CW
Limit Input Signal Flag
This is the CW limit input signal for
pulse output 2, which is used in the
origin search. To use this signal, write
the input from the actual sensor as an
input condition in the ladder program
and output the result to this flag.
--- Retained Cleared ---
09 Pulse Output 2 CCW
Limit Input Signal Flag
This is the CCW limit input signal for
pulse output 2, which is used in the
origin search. To use this signal, write
the input from the actual sensor as an
input condition in the ladder program
and output the result to this flag.
--- Retained Cleared ---
10 Pulse Output 2
Positioning
Completed Signal
This is the positioning completed input
signal used in the origin search for
pulse output 2. The input signal from
the servo driver is output to this bit
from the ladder program to enable
using the signal.
--- Retained Cleared ---
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
