5
Section 2 - Technical Specifications
V520-LHA7127
Section 2
Technical Specifications
Physical Specifications
Case Material Steel (black)
Dimensions Side View
)Front View
(LxHxW) 52 x 20 x 55 mm 47 x 20 x 55 mm
(1.85 x 0.78 x 2.2 in) (1.95 x 0.78 x 2.2 in)
Weight 100 g (3.5 ounces) without cable
Cable length 6.5 feet (2000 mm)
Connector 2.8 m (6 ft) with DB25 pin female connector
Mounting 4 threaded (M-3) mounting holes (2 on each side)
(not to extend more than 3 mm into the case)
Symbologies Supported
• Codabar (NW-7)
• Code 39
• Code 93
• Code 128
• Industrial 2 of 5
• Interleaved 2 of 5
• MSI / Plessey
• WPC (UPC / EAN / JAN)
•IATA
Optical Specifications
Scan rate 700 scans per second ±10%
Wavelength of LED Illumination 660 nanometers
Read Sensor CCD linear array
Focal Distance Side View
Front View
(nominal) 1.2 inches from window 1.4 inches from window
Narrow Bar Resolution 5.0 mil at 0.9 PCS
Minimum PCS 0.45 (min. backround reflectance of 70%)
