Omron V520-LHA7127 User Manual

6
Section 2 - Technical Specifications
V520-LHA7127
Pitch
Note Recommended operation at 10° ≤ α
1
, α
2
≤ 15°. Avoid specular reflection
dead zone (hatched).
Skew
Tilt (Rotation)
α
1
α
2
α
1
α
2
Front View
Side View
Hatched no
read specular
zone ±10˚
Height
of barcode
20˚
OK
OK
10˚
10˚
20˚
30˚
30˚
Height
of barcode
Hatched no
read specular
zone ±13˚
OK
OK
13˚
15˚
15˚
10˚
10˚
25˚
25˚
Front View
Side View
β
β
β = 0 to 6˚
(h = 35.4 mm, α
2
= 10˚, θ = 0˚, R = ∞)
β = 0 to 6˚
(h = 31.4 mm, α
2
= 10˚, θ = 0˚, R = ∞)
β
β
Side View
Front View
θ
θ
θ
θ
θ = 0 to 10˚
(h = 31.4 mm, α
2
= 10˚, β = 0˚, R = ∞)
θ = 0 to 10˚
(h = 35.4 mm, α
2
= 10˚, β = 0˚, R = ∞)
