Omron V520-LHA7127 User Manual

57
Appendix A - Programming Menus & Commands
V520-LHA7127
30.Sequencer Controls
* Use Z2 computer command to store in memory prior to power off.
Continued on next page.....
Computer Command Function/Description Bar Code Command
(Z7)
START/END
Programming Menu
-[8-
8A
Trigger Input (sync signal positive
logic) High active
-9B-
8B
Trigger Input (sync signal
negative logic) Low active
-9C-
8C
Sequencer output
synchronous transmission *
-9D-
8D
Sequencer output
synchronous transmission *
(negative – true logic)
-9E-
8E
Sequencer output
one-shot transmission *
-9F-
8F
Sequencer output
one-shot transmission *
(negative – true logic)
-9G-
8G
Sequencer output
one-shot duration 10 mS
-9H-
8H
Sequencer output
one-shot duration 20 mS
-9I-
8I
Sequencer output
one-shot duration 30 mS
-9J-
8J
Sequencer output
one-shot duration 40 mS
-9K-
8K
Sequencer output
one-shot duration 50 mS
-9L-
8L
Sequencer output
one-shot duration 60 mS
-9M-
