ZX Series (ZX-L-N) Smart Sensors (Laser Type) 15
Part Names
Amplifier Units
ZX-LDA11-N
ZX-LDA41-N
Sensor Heads (Reflective)
ZX-LD40
ZX-LD100
ZX-LD300
ZX-LD40L
ZX-LD100L
ZX-LD300L
ZX-LD30V*
ZX-LD30VL*
Calculating Unit
ZX-CAL2
Receiver
(Optical filter)
Output cable (with connector)
Input cable (with connector)
Display area
Controls
Output cable
Connector
(Cover opens and closes.)
Display area
Connector
Display area
Sensor Heads (Through-beam)
ZX-LT001
ZX-LT005
ZX-LT010
ZX-LT030
Emitter
Laser ON
indicator (green)
Lit when light is
emitted.
Light emitter
Receiver side
(Optical filter)
Emitter side
sensor head
connector
Receiver side sensor
head connector
Receiver
Emitter
*The dimensions for these models are slightly different. Refer to page 23 for details.
