ZX Series (ZX-L-N) Smart Sensors (Laser Type) 5
■ Amplifier Units
Item Model ZX-LDA11-N ZX-LDA41-N
Measurement period 150
µs
Possible average count settings*1
*1. The response speed of the linear output is calculated as the measurement period
× (average count setting + 1) (with fixed sensitivity).
The response speed of the judgement outputs is calculated as the measurement period
× (average count setting + 1) (with fixed sensitivity).
1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1,024, 2,048, or 4,096
Temperature characteristic When connected to a Reflective Sensor Head: 0.01% FS/
°C, When connected to a Through-beam Sensor
Head: 0.1% FS/
°C
Linear output*2
*2. The output can be switched between a current output and voltage output using a switch on the bottom of the Amplifier Unit.
4 to 20 mA/FS, Max. load resistance: 300
Ω, ±4 V (± 5 V, 1 to 5 V *3), Output impedance: 100 Ω
*3. Setting is possible via the monitor focus function.
Judgement outputs
(3 outputs: HIGH/PASS/LOW)*1
NPN open-collector outputs, 30 VDC, 50 mA max.
Residual voltage: 1.2 V max.
PNP open-collector outputs, 30 VDC, 50 mA max.
Residual voltage: 2 V max.
Laser OFF input, zero reset input,
timing input, reset input
ON: Short-circuited with 0-V terminal or 1.5 V or less
OFF: Open (leakage current: 0.1 mA max.)
ON: Supply voltage short-circuited or supply voltage
within 1.5 V
OFF: Open (leakage current: 0.1 mA max.)
Functions Measurement value display, present value/set value/light level/resolution display, scaling, display reverse,
display OFF mode, ECO mode, number of display digit changes, sample hold, peak hold, bottom hold,
peak-to-peak hold, self-peak hold, self-bottom hold, average hold, delay hold, intensity mode, zero reset,
initial reset, ON-delay timer, OFF-delay timer, one-shot timer, deviation, previous value comparison,
sensitivity adjustment, keep/clamp switch, direct threshold value setting, position teaching, 2-point
teaching, automatic teaching, hysteresis width setting, timing inputs, reset input, monitor focus, linear
output compensation, (A-B) calculations*4, (A+B) calculations*4, mutual interference*4, laser
deterioration detection, zero reset memory, zero reset display, key lock
*4. A Calculating Unit (ZX-CAL2) is required.
Indications Operation indicators: High (orange), pass (green), low (yellow), 7-segment main display (red), 7-segment
subdisplay (yellow), laser ON (green), zero reset (green), enable (green)
Power supply voltage 12 to 24 VDC
±10%, Ripple (p-p): 10% max.
Current consumption 140 mA max. with power supply voltage of 24 VDC (with Sensor connected)
Ambient temperature Operating: 0
to 50°C, Storage: −15 to 60°C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Insulation resistance 20 M
Ω min. at 500 VDC
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min
Vibration resistance
(destruction)
10 to 150 Hz, 0.7-mm double amplitude 80 min each in X, Y, and Z directions
Shock resistance
(destruction)
300 m/s
2
3 times each in six directions (up/down, left/right, forward/backward)
Connection method Prewired (standard cable length: 2 m)
Weight (packed state) Approx. 350 g
Materials Case: PBT (polybutylene terephthalate), Cover: Polycarbonate
Accessories Instruction sheet
