ZX2
Specifications
Diffuse-reflective Sensor Heads
Regular-reflective Sensor Head
Note: False detection outside the measurement range can occur in the case of an object with high reflectance.
*1. Beam size: Defined as 1/e
2
(13.5 %) of the center optical intensity at the minimum value of the measurement range (effective value).
False detections can occur in the case there is light leakage outside the defined region and the surroundings of the target object have a high
reflectance in comparison to the target object. Correct measurements may not be obtained if the workpiece is smaller than the beam size.
*2. Resolution: indicates the degree of fluctuation (±3σ) of analog output when connected to the ZX2-LDA.
(The measured value is given for the center distance for OMRON’s standard target object (diffuse-reflective models: white ceramic object,
regular-reflective models:1/4 λ flat mirror) when the response time of the ZX2-LDA is set to 128 ms.)
Indicates the repetition accuracy for when the workpiece is in a state of rest. Not an indication of distance accuracy.
Resolution performance may not be satisfied in a strong electromagnetic field.
*3. Linearity: indicates the error with respect to the ideal straight line of the displacement output in the case of measuring Omron’ s standard target
object. Linearity and measured value may vary depending on target object.
F.S. indicates the full scope of the measurement range. (ZX2-LD50(L): 20 mm)
*4. Temperature characteristic: Value for the case the space between the sensor head and Omron’ s standard target object is secured by an
aluminum jig. (Measured at the measurement center distance)
*5. These Sensors are classified as Class 2 laser devices for diffuse-reflective models and Class 1 for regular-reflective models under EN 60825-
1 and the regulations of Laser Notice No. 50 for FDA certification. CDRH registration has been completed.
Item Model ZX2-LD50L ZX2-LD50 ZX2-LD100L ZX2-LD100
Optical system Diffuse reflective
Light source
(wave length)
Visible-light semiconductor laser with a wavelength of 660 nm and an output of 1mW max.
EN class 2, FDA class 2 *5
Measurement center point 50 mm 100 mm
Measurement range ±10 mm ±35 mm
Beam shape Line Spot Line Spot
Beam size *1 Approx. 60 μm × 2.6 mm Approx. 60 μm dia. Approx.110 μm × 2.7 mm Approx. 110 μm dia.
Resolution *2 1.5 μm5 μm
Linearity *3 ±0.05% F.S. (40 to 50 mm) ±0.1% F.S. (40 to 50 mm)
±
0.05% F.S. (65 to 100 mm)
±0.1% F.S. (65 to 100 mm)
Temperature characteristic
*4 0.02% F.S. /°C
Ambient illumination Incandescent lamp: 10,000 lx max. (on light receiving side)
Ambient temperature Operating: 0 to 50 °C, Storage: −15 to 70 °C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min.
Vibration resistance (destruction)
10 to 150 Hz, 0.7-mm double amplitude, 80 min. each in X, Y, and Z directions
Shock resistance (destruction)
300 m/s
2
3 times each in six directions (up/down, left/right, forward/backward)
Degree of protection IEC60529, IP67
Connection method Connector connection (standard cable length: 500 mm)
Weight (packed state) Approx. 160 g (main unit only: Approx. 75 g)
Materials Case and cover: PBT (polybutylene terephtahalate), Optical window: Glass, Internal thread: Brass, Cable: PVC
Accessories Instruction sheet, Ferrite core ×1 (made by TDK Corp. ZCAT1730-0730A), Laser warning label (English), FDA
Item Model ZX2-LD50V
Optical system Regular reflective
Light source (wave length)
Visible-light semiconductor laser with a wavelength of 660 nm and an output of 0.24 mW max. EN class 1, FDA class 1 *5
Measurement center point 48mm
Measurement range ±5mm
Beam shape Spot
Beam size *1 Approx. 60 μm dia.
Resolution *2 1.5 μm
Linearity *3 ±0.3%F.S. (entire range)
Temperature characteristic
*4 0.06%F.S./°C
Ambient illumination Incandescent lamp: 10,000lx max. (on light receiving side)
Ambient temperature Operating: 0 to 50 °C, Storage: -15 to 70 °C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Dielectric strength 1,000 VAC, 50/60 Hz for 1 minute
Vibration resistance (destruction)
10 to 150 Hz, 0.7-mm double amplitude, 80 minutes, each in X,Y,and Z directions
Shock resistance (destruction)
300 m/s
2
3 times each in six directions (up/down,left/right,forward/backward)
Degree of protection IEC 60529, IP67
Connection method Connector connection (standard cable length: 500 mm)
Weight (packed state) Approx.160g (Sensor Head only: Approx.75g)
Materials Case and cover: PBT (polybutylene terephtahalate), Optical window: Glass, Internal thread: Brass, Cable: PVC
Accessories Instruction sheet, Ferrite core ×1 (made by TDK Corp. ZCAT1730-0730A), Laser warning label (English), FDA
