1.4 Technical Specifications
Model Polar 350
Input Power 110–120 V
~
60 Hz
Power Consumption 600 W
Rated Power 50 W
Expected Service Life
at <40% / 40–70% / >70% Power
11,000 / 10,000 / 8,000 hr.
Laser Wavelength 10.6 μm (10,600 nm)
Laser Tube
Diameter 2.2 in. 5.5 cm
Length 35 in. 90 cm
Mirror
Diameter 0.8 in. 20.5 mm
Thickness 0.12 in. 3 mm
Focus Lens
Diameter 0.6 in. 15.5 mm
Thickness 0.08 in. 2 mm
Focal Length 2 in. 50.8 mm
Honeycomb Workbed Dimensions 22.5×13.2×0.9 in. 57.1×33.6×2.2 cm
Processing Area
Standard
(L×W)
20.1×11.8 in. 510×300 mm
Trayless
(L×W)
13.7×8.2 in. 350×210 mm
Rotary 1 0–9.4×2.4–2.9 in. 0–240×60–75 mm
Rotary 2 0–9.4×1.2–2.3 in. 0–240×30–60 mm
Front/Back Pass-Through Area
(L×H)
14.1×0.19 in. 360×5 mm
Max. Processing Speed 19.7 ips 500 mm/s
Max. Material
Thickness
Standard 0.59 in. 1.5 cm
Without Workbed 1.9 in. 5 cm
Max. Resolution 1000 dpi
Min. Letter Size 0.04×0.04 in. 1×1 mm
Mainboard Ruida 6442S (RDC6442S-B)
Integrated
Water Chiller
Capacity 1.6 qt. 1.5 L
Flow Rate 142 gph 540 L/hr.
Integrated
Air Assist
Port Diameter 0.4 in. 10 mm
Air Flow 18.8 cfm 533 L/min.
Integrated
Digital Camera
Max. Resolution 5 MP
Field of View 20.1×11.8 in. 51×30 cm
Accuracy ±0.04 in. ±1 mm
External
Exhaust Fan
Rated Power 60 W
Port Diameter 5.9 in. 150 mm
Air Flow 282/353 cfm 480/600 m³/hr.
Req. Operating
Environment
Max. Humidity 20–85%
Temp. Range 40–104°F 5–40°C
Provided Operating Software RDWorks
Compatible Operating Software CorelLaser, CADLaser, LightBurn
Certification CE, FDA
Dimensions 38.2×22.3×9.2 in. 97×56.5×23.4 cm
Net Weight 104 lb. 47 kg
