MANTA USER’S MANUAL
15
04
uSe and conFiguration oF the equiPMent
4.2.3. charging the controLLer
1. Connect the Qi charger through a USB.
2. Place the controller on the centre of the Qi as shown in the
drawing below.
3. When charging, the green LED of the Wireless Controller will
begin to blink.
4. Once the controller is fully charged, the LED will turn o.
5. To check the status of the battery of the controller please pick it
up and press on the drop to see the battery LED.
4.3. LeaSh
1. Attach the leash right below the knee of the front leg, as shown
on the drawing below.
2. Once the rider is ready to use the board, place the security
magnet key on the board.
The magnetic key is a security mechanism, the jet will not
activate if this key is not properly placed.
3. In case of fall, the magnetic key will detach, stopping the jet.
Once the rider is back on the board ready to continue its use,
the magnetic key should be properly placed again.
SYNC BATTERY
mANTA
Magnetic Key
Connector
To Next Page
