MANTA USER’S MANUAL
9
03
First Assembly
3.3. inSert the battery Magnet
Before using the unit for the first time, the cylindrical magnet must be
inserted in the hole inside the battery compartment.
3.4 inSert FeMaLe conectorS
Please, screw the female connectors, found in the wireless controller case,
in the holes of the bottom part of the battery using the tool provided on the
tooling kit.
3.5. PoSitioning the FootStraPS
The board incorporates inserts valid for both goofy and regular riders.
1. Depending on the style of riding, place the footstraps over the desired
inserts. One on the front of the board and one on the back.
2. Place the screw through the screw insert and hold the footstrap.
3. Align the holes with the footstrap insert.
4. Screw the footstrap to secure it.
mANTA
Footstraps inserts
Footstrap insert
Footstrap screw
Screw
insert
Battery magnet
Battery compartment
Insert for the battery
magnet
Female
connectors
Battery bottom
