MANTA USER’S MANUAL
6
02
Packing List
2. Packing LiSt
The following describes a list of the
components included with the equipment
and a description of them.
2.1. Manta board
Construction with EPS core and laminated
breglass and epoxy full sandwich.
• Weight (without the battery): 17 kg / 37
lbs
• Length: 230 cm / 7´6”
• Width: 90 cm / 35.4”
• Thickness: 15 cm / 5.9”
• Volume: 200 l
2.3. 2 Jet Unit
• Nominal power: 800 kW
• Nominal voltage: 44,4 VDC
• Static push: 500 W
2.4. Battery
Short circuit, overcharge and temperature
protection. Waterproof.
• Type: multicell Litio-Ion
• Weight: 14 kg / 30 lbs
• Max. electric discharge: 130 A.
• Nominal capacity: 40.0 Ah
• Nominal voltage: 44.4 V
• IP68 Certied
2.5. Chargers
Over voltage protection. Thermal
protection. Short circuit protection. Reverse
polarity protection. Charging indicator.
• Input power: 220-230 VAC (*Also
available 110 VAC)
• Charging current: 15 A
• Output voltage: 50,4 VDC
2.6. Remote Control
Watertight. Thrust display. Battery display.
Pressure sensor Drop. Induction charging.
• Frequency: 2.4 GHz
• Battery: LiPo 300 mAh
2.7 Grease
White grease for battery connectors, blue
grease for mechanical maintenance.
