11451 Belcher Road South, Largo, FL 33773 • USA • Tel +1 (727) 447-6140 • Fax +1 (727) 442-5699 • sales@onicon.com
F-5500 Thermal Mass Flow Meter Manual 06/17 - 2030 / 107023 Page 3
Model F-5500
TABLE OF CONTENTS
Table Of Contents
1. Introduction Page 5
a. Menu Trees Page 5
b. Quick Start Guide Page 15
2. Installation (Mechanical) Page 17
a. Installation Depth Page 22
b. Orientation of Flowmeter Page 24
c. Rotating the Probe/Enclosure Page 21
d. Sensor Elements Page 21
e. Changing the Orientation of the Display Page 28
f. Compression Fittings Page 24
3. Wiring (Electrical) Page 29
a. General Wiring Page 30
b. Input Power Page 30
c. Signal Wiring Page 31
d. Pulse/Alarm Wiring (optional feature) Page 33
e. RS485 Wiring: Modbus RTU or BACnet MS/TP (optional feature) Page 35
f. HART wiring Page 36
4. Operation (Standard Operation) Page 39
a. Start Up Page 39
b. Programming Page 41
c. Zero CAL-CHECK
®
Page 58
5. Communication Protocols Page 62
a. RS485 Modbus RTU Page 62
b. BACnet MS/TP Page 69
c. HART Page 73
6. Maintenance Page 78
a. Precautions Page 78
b. General Page 79
c. Troubleshooting Page 80
7. Appendices Page 86
a. Specifications Page 86
b. Agency Approvals Page 88
c. Dimensions Page 89
d. Warranty Page 89
e. Returning your meter Page 93
8. Glossary of Terms and Abbreviations Page 94
9. Index Page 95
