F-5500 Thermal Mass Flow Meter Manual 06/17 - 2030 / 107023 Page 73
Model F-5500
COMMUNICATIONS
Model F-5500
COMMUNICATIONS
Scope
The ONICON’ Model F-5500 transmitter complies with HART Protocol Revision 7.1.
This section specifies all the device-specific features and documents HART Protocol
implementation details (e.g., the Engineering Unit Codes supported). The functionality
of this Field Device is described sufficiently to allow its proper application in a process
and its complete support in HART-capable Host Applications.
Purpose
This section provides a complete description of this Field Device from a HART
Communication perspective.
The specification in this section is designed to be a technical reference for HART
capable Host Application Developers, System Integrators and knowledgeable End
Users. It also provides functional specifications (e.g., commands and performance
requirements) used during development, maintenance and testing. The information
given in this section assumes the reader is familiar with HART Protocol requirements
and terminology.
References
HART Smart Communications Protocol Specification. HCF_SPEC-12. Available from
the HCF.
Device Identification
Manufacturer
Name: ONICON Inc Model Name(s): F-5500
Manufacturer ID
Code: 0x60D4 hex Device Type Code:
57583
(EOEF Hex)
HART Protocol
Revision 7.1 Device Revision: 1
Number of Device
Variables None
Physical Layers
Supported FSK
Physical Device
Category
Transmitter,
DC-isolated Bus Device
