Connections
En-9
∫ Other connection method
Connection to a CD player via DIGITAL (North
American and Continental European models):
Connect the coaxial digital cable to the COAXIAL (D1)
jack. Connect the RI cable to the REMOTE
CONTROL jack. Set the RI MODE (CD) switch to D1.
Connection to an RI dock via LINE: Connect the audio
pin cable to the LINE IN 2 jack. Connect the RI cable
to the REMOTE CONTROL jack.
(North American and Continental European models) Set
the RI MODE (DOCK) switch to LINE2.
Connection to an RI dock via DIGITAL (North
American and Continental European models):
Connect the optical digital cable to the OPTICAL (D2)
jack. Connect the RI cable to the REMOTE
CONTROL jack. Set the RI MODE (DOCK) switch to
D2.
Connection to a tuner via LINE: Connect the audio pin
cable to the LINE IN 3 jack. Connect the RI cable to
the REMOTE CONTROL jack.
0 (North American and Continental European models)
The link function of RI is not supported when a tuner is
connected via DIGITAL. Do not connect the RI cable.
∫ When connecting two or more RI equipment
When there are two RI terminals on the equipment, one
can be connected to this unit and the other can be
connected to other equipment, allowing to link both
equipment to this unit. Similarly, it is possible to increase
the equipment to be linked. There is no specification for
order to connect the equipment.
A-9010_eng.book 9 ページ ２０１４年１２月２５日 木曜日 午前１０時４８分

Onkyo A-9010 Specifications

General

Damping factor	95
Amplifier class	-
Frequency range	10 - 100000 Hz
Input sensitivity	150 mV
Audio output channels	2.0 channels
Peak power per channel	44 W
Signal-to-Noise Ratio (SNR)	92 dB
Total Harmonic Distortion (THD)	0.08 %
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	25 W
Package weight	8200 g
Manual	Yes

Weight and Dimensions

Depth	3 mm
Width	435 mm
Height	129.5 mm
Weight	6500 g
