Onkyo A 9555

4/27 PAGE
EV U08 VOLUME LED PC board ass'y NAETC-8713-1K 1 --- NSP, <DC>
EV U08 VOLUME LED PC board ass'y NAETC-8713-1F 1 --- NSP, <PP>
EV U08 VOLUME LED PC board ass'y NAETC-8713-1G 1 --- NSP, <GT>
EV U08 VOLUME LED PC board ass'y NAETC-8713-1J 1 --- NSP, <DT>
EV U08 VOLUME LED PC board ass'y NAETC-8713-1H 1 --- NSP, <GR>
EV U09 POWER SUPPLY PC board ass'y NAPS-8714-1K 1 1B093514-1K <DC>
EV U09 POWER SUPPLY PC board ass'y NAPS-8714-1F 1 1B093514-1F <PP>
EV U09 POWER SUPPLY PC board ass'y NAPS-8714-1G 1 1B093514-1G <GT>
EV U09 POWER SUPPLY PC board ass'y NAPS-8714-1J 1 1B093514-1J <DT>
EV U09 POWER SUPPLY PC board ass'y NAPS-8714-1H 1 1B093514-1H <GR>
EV U11 POWER SWITCH PC board ass'y NAETC-8716-1K 1 --- NSP, <DC>
EV U11 POWER SWITCH PC board ass'y NAETC-8716-1F 1 --- NSP, <PP>
EV U11 POWER SWITCH PC board ass'y NAETC-8716-1G 1 --- NSP, <GT>
EV U11 POWER SWITCH PC board ass'y NAETC-8716-1J 1 --- NSP, <DT>
EV U11 POWER SWITCH PC board ass'y NAETC-8716-1H 1 --- NSP, <GR>
EV U12 SPEAKER SELECTOR PC board ass'y NAETC-8718-1K 1 --- NSP, <DC>
EV U12 SPEAKER SELECTOR PC board ass'y NAETC-8718-1F 1 --- NSP, <PP>
EV U12 SPEAKER SELECTOR PC board ass'y NAETC-8718-1G 1 --- NSP, <GT>
EV U12 SPEAKER SELECTOR PC board ass'y NAETC-8718-1J 1 --- NSP, <DT>
EV U12 SPEAKER SELECTOR PC board ass'y NAETC-8718-1H 1 --- NSP, <GR>
EV U13 STANDBY LED PC board ass'y NAETC-8719-1K 1 --- NSP, <DC>
EV U13 STANDBY LED PC board ass'y NAETC-8719-1F 1 --- NSP, <PP>
EV U13 STANDBY LED PC board ass'y NAETC-8719-1G 1 --- NSP, <GT>
EV U13 STANDBY LED PC board ass'y NAETC-8719-1J 1 --- NSP, <DT>
EV U13 STANDBY LED PC board ass'y NAETC-8719-1H 1 --- NSP, <GR>
A-955
5
PC BOARD PARTS LIST
PCB1
U01 AMPLIFIER PC BOARD (NAAF-8708-1B)
PCB1
U02 TONE CONTROL PC BOARD (NAAF-8710-1B)
PCB1
U03 HEADPHONE JACK PC BOARD (NAETC-8717-1B)
PCB1
PCB1
CIRCUIT NO.
NAME DESCRIPTION Q'TY PART NO. REMARKS
PCB1
Q615 PHT CP TLP283-4 1 24120130R2
PCB1
Q671 PHT CP TLP283 1 24120133R2
PCB1
Q201 IC NJW1157B 1 22242193R3
PCB1
Q301 IC NE5532AP(TI) 1 22242274
PCB1
Q302 IC NE5532AP(TI) 1 22242274
PCB1
Q341 IC NE5532AP(TI) 1 22242274
PCB1
Q348 IC NE5532AP(TI) 1 22242274
PCB1
Q413 IC TC74AC14FT 1 22242217R2
PCB1
Q414 IC TC74AC14FT 1 22242217R2
PCB1
Q415 IC TC74AC00FT 1 22242244R2
PCB1
Q416 IC TC74AC00FT 1 22242244R2
PCB1
Q525 IC 78M12HF(NJM78M12FA) 1 222780125JRC
PCB1
Q526 IC 78L05(NJM78L05UA) 1 222780053R2JR
PCB1
Q529 IC 78L05(NJM78L05UA) 1 222780053R2JR
PCB1
Q530 IC 78L05(NJM78L05UA) 1 222780053R2JR
PCB1
Q536 IC 78M12HF(NJM78M12FA) 1 222780125JRC
PCB1
Q613 IC M51957BFP 1 22241239R2
