Onkyo CR-245 - Display; Rear Panel

En-10
Getting to Know the CD receiver—Continued
a
SLEEP indicator
b Play  and Pause  indicators
c FOLDER indicator
d S.BASS indicator
e MUTING indicator
f Playback mode indicators
g TIMER indicators
h Tuning indicators
i FILE indicator
j TRACK indicator
k Message area
l DISC, TOTAL, and REMAIN indicators
a FM ANTENNA jack
b AM ANTENNA jack
c LINE IN jack
d VIDEO OUT jack
e AUDIO OUT (SUBWOOFER) jack
f SPEAKERS terminals
g AC INLET
Display
ˆˆˆ„„ˆˆ…„ˆˆ„„ˆ„„ˆˆ…‡ˆˆ
a 4 5 6b 3
7k9j l8
Rear Panel
2a 3 4 5 6 7
See pages 14 to 16 for connection information.
