10
Part Names and Functions—Continued
The speakers are symmetrical. Locate them as you
desire.
Tip
If you locate the speakers so that the tweeters are on the
outside, the stereo field will be widened. If the tweeters are
on the inside, the audio will sound more direct and tighter.
This speaker system uses detachable grilles. Use the
following method to attach or detach the grilles.
1. While holding the bottom edge of the speaker grille
with both hands, pull it gently toward you to remove
the bottom of the grille.
2. In the same way, gently pull the upper edge of the
speaker grille toward you to remove it from the
main unit.
3. To replace the grille, push the holders at the four
corners into the grille attachment pins on the
speaker cabinet.
Speakers
Tweeter Grille attachment pin Grille
Woofer Cabinet
Attaching and detaching the speaker
grilles
Detaching Attaching
To Next Page
