DR-C500
DR-C500
M41
(3x)
(3x)
M42
(2x)
M43
M44
M46
M47
M48
M49
M50
M51
(2x)
EXPLODED VIEWS OF DVD MECHANISM-3
DWS ASY DRAWER
LUBRICANT GRASE
around the bosss
and around the ring
LUBRICANT GREASE
around the teeth
LUBRICANT GREASE
along on the top area
LUBRICANT GREASE
inside and along
the curve
LUBRICANT GREASE
inside the slots
and along the slots
LUBRICANT GREASE
along the crossed area
Put in a separately bag
Driver Moment
12 N/cm +/- 2 N
