Onkyo HT-R320 Service Manual

HT-R320
SPECIFICATIONS
Amplifier Section
THD(Total Harmonic Distortion):
Damping Factor:
Input Sensitivity and Impedance:
Output Level and Impedance:
Frequency Response:
Tone Control:
SN Ratio:
Speaker Impedance:
Video Section
Input Sensitivity
/Output Level and Impedance:
Tuner Section
AM
Tuning Frequency Range:
Usable Sensitivity:
S/N Ratio:
THD:
DVD, VIDEO 1, VIDEO 2, VIDEO 3
Video Outputs
A/V Output: MONITOR OUT, VIDEO 1
1 (Optical), 1 (Coaxial)
DVD, MULTICHANNEL, CD, TAPE,
VIDEO 1, VIDEO 2, VIDEO 3
5.1
Specifications and features are subject to change without notice.
Power Output:
Front L/R:
Center
Surround L/R
Dynamic Power:
100 W + 100 W
100 W
100 W + 100 W
(8 , 20 Hz~20 kHz, FTC)
230 W + 230 W (3 , Front)
170 W + 170 W (4 , Front)
115 W + 115 W (8 , Front)
0.08 % (Power Rated)
60 (Front, 1 kHz, 8 )
200 mV/ 47 k (LINE)
200 mV/ 2.2 k (REC OUT)
10 Hz~100 kHz / +0 dB -3 dB (Direct mode)
+12 dB, -12 dB, 50 Hz (BASS)
+12 dB, -12 dB, 20 kHz (TREBLE)
100 dB (CD, IHF-A)
8 ~ 16
1 Vp-p /75 (Composite)
TAPE, VIDEO 1
1
5 + 2
1
530 kHz~1710 kHz
30 µV
40 dB
0.70 %
General
Power Supply:
Power Consumption:
Stand-by Power Consumption:
Dimensions (W H D):
Weight:
AC 120 V, 60 Hz
4.7 A
1.6 W
17-1/8 5-7/8 14-3/4 inches
435 150 374 mm
8.8 kg (19.4 lbs )
FM
Tuning Frequency Range:
Usable Sensitivity:
S/N Ratio:
THD:
Stereo Separation:
Video Inputs
A/V Input:
Audio Inputs
Digital Inputs:
Analog Inputs:
Multichannel Inputs:
Audio Outputs
Analog Outputs:
Subwoofer Pre Outputs:
Speaker Outputs:
Phones:
87.5 MHz~108.0 MHz
Stereo 17.2 dBf 2 µV (75 IHF)
Mono 11.2 dBf 1 µV (75 IHF)
Stereo 70 dB (IHF-A)
Mono 76 dB (IHF-A)
Stereo 0.3 % (1 kHz)
Mono 0.2 % (1 kHz)
45 dB ( 1 kHz )

Onkyo HT-R320 Specifications

General

Brand	Onkyo
Model	HT-R320
Category	Receiver
Language	English
