Onkyo HT-R320 Service Manual

1/30 PAGE
HT-R320
EXPLODED VIEW PARTS LIS
T
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
EXP.
A002 SCREW 3TTF+8B(BC) 2 835430088
EXP.
A004 SCREW 3TTB+8B 1 838130088
EXP.
A005 SCREW 3TTB+10B(BC) 10 838430108
EXP.
A007 SCREW 3TTB+10B(BC) 3 838430108
EXP.
A010 CHASSIS --- 1 27100416A
EXP.
A015 HOLDER KGLS-8RT 1 27190503A
EXP.
A016 HOLDER KGPS-10RF 2 27190813
EXP.
A017 HOLDER KGLS-10RT 3 27190428A
EXP.
A020 SCREW 3TTB+8B 6 838130088
EXP.
A021 SCREW 3TTB+8B 4 838130088
EXP.
A022 SCREW 3TTB+8B 1 838130088
EXP.
A023 SCREW 4TTC+8C(BC) 4 830440089
EXP.
A024 SCREW 3TTB+8B 1 838130088
EXP.
A025 RIVET P-RIVET NRP-345 1 880009
EXP.
A026 SCREW 3TTW+8B(BC) 1 831430088
EXP.
A028 BUSHING S-RELIEF #2271 1 27300750
!
EXP.
A030 HEAT SINK AS 1 27160501
EXP.
A035 SCREW 3TTB+8B 1 838130088
EXP.
A036 SCREW 3TTB+8B 2 838130088
EXP.
A037 SCREW 3SMS8W.SW+14B(BC) 10 801433
EXP.
A050 COVER --- 1 28184906
EXP.
A051 SCREW 3TTB+8B(UN) 6 838930088
EXP.
A055 LEG LEG 4 27175319B
EXP.
A056 CUSHION --- 8 28141494
EXP.
A057 SCREW 3TTB+8B 4 838130088
EXP.
A060 KNOB (VOL)AS 1 28326255
EXP.
A065 CLEAR PLT (S) 1 28192046
EXP.
A401 REAR PANEL --- 1 27123377
EXP.
A404 SCREW 3TTB+8B(BC) 24 838430088
EXP.
A410 F PANEL --- 1 27212722
EXP.
A411 KNOB (POW) 1 28326250
EXP.
A412 KNOB (MODE) 1 28326254
EXP.
A413 KNOB (SEL) 1 28326252
EXP.
A414 KNOB (PRE) 1 28326253
EXP.
A415 TAPE (CU) 1 29110161
EXP.
A416 TAPE (CU) 2 29110170
EXP.
A417 TAPE (CU) 1 29110171
EXP.
A418 TAPE (CU) 1 29110172
EXP.
A420 BADGE --- 1 28135290
EXP.
A421 SCREW 3TTW+8B(BC) 3 831430088
EXP.
A425 LABEL HOOKUP-ONKYO 1 29363194
EXP.
A435 LABEL (POP) 1 O
EXP.
F6901 FUSE 8A-UL 1 252198
!
EXP.
F6901 or FUSE 8A-T/UL-ST2 ( 1) 252261
!
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
