Onkyo HT-R320 Service Manual

4/30 PAGE
PCB1
Q313 TR RN1441 1 2215410R2
PCB1
Q321 IC(REGULATOR) 78L07(SMT) 1 222780073R2
PCB1
Q322 IC(REGULATOR) 79L07(SMT) 1 222790073R2
PCB1
Q701 IC CS493264 1 22241762R2
PCB1
Q707 IC TC7WU04FU 1 22240935R2
PCB1
Q801 IC AK4586 1 22241620R3
PCB1
Q802 IC NJM4565M-D 1 22241383R2
PCB1
Q802 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB1
Q802 or IC NJM4565M ( 1) 22240581R2
PCB1
Q803 IC NJM4565M-D 1 22241383R2
PCB1
Q803 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB1
Q803 or IC NJM4565M ( 1) 22240581R2
PCB1
Q804 IC NJM4565M-D 1 22241383R2
PCB1
Q804 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE
PCB1
Q804 or IC NJM4565M ( 1) 22240581R2
PCB1
Q6402 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS
PCB1
Q6402 or IC(REGULATOR) 78M12HF ( 1) 222780125
PCB1
Q6402A SCREW 3P+10FN(BC) 1 82143010
PCB1
Q6402B HEAT SINK RAD-183 1 27160526
PCB1
Q6402C TAPE TAPE(CLOTH-16U) 1 29110083
PCB1
Q6403 IC(REGURATOR) 79012HF(TA79012S) 1 222790124TOS
PCB1
Q6403 or IC(REGULATOR) 79M12HF ( 1) 222790125
PCB1
Q6405 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS
PCB1
Q6405 or IC(REGULATOR) 78M12HF ( 1) 222780125
PCB1
Q6405A SCREW 3P+10FN(BC) 1 82143010
PCB1
Q6406 IC(REGURATOR) 7805HF(TA7805S) 1 222780054TOS
PCB1
Q6406 or IC(REGULATOR) 78M05HF ( 1) 222780055
PCB1
Q6406A SCREW 3P+10FN(BC) 1 82143010
PCB1
Q7001 TR RN1404 1 2214490R2
PCB1
Q7001 or TR KRC104S ( 1) 2216210R2
PCB1
Q7002 IC TC74VHC541FT 1 22274541ER2TO
PCB1
Q7002 or IC SN74AHC541PWR ( 1) 22274541IR2TI
PCB1
Q7003 IC TC74HCT7007AF 1 222740077R2TO
PCB1
Q7004 IC BA33C25FP 1 22241778R2
PCB1
Q7006 TR RN1404 1 2214490R2
PCB1
Q7006 or TR KRC104S ( 1) 2216210R2
PCB1
Q7007 TR RN1404 1 2214490R2
PCB1
Q7007 or TR KRC104S ( 1) 2216210R2
PCB1
Q7008 IC MPD784225GC-249-8BT 1 22242149R3
PCB1
Q9501 TR 2SA1015-GR 1 2211455
PCB1
D801 C-DIODE 1SS352 1 223234R2
PCB1
D801 or C-DIODE 1SS355 ( 1) 223269R2
PCB1
D802 C-DIODE 1SS352 1 223234R2
PCB1
D802 or C-DIODE 1SS355 ( 1) 223269R2
PCB1
D7001 C-DIODE 1SS352 1 223234R2
PCB1
D7001 or C-DIODE 1SS355 ( 1) 223269R2
PCB1
D7002 C-DIODE 1SS352 1 223234R2
PCB1
D7002 or C-DIODE 1SS355 ( 1) 223269R2
PCB1
D7003 C-DIODE 1SS352 1 223234R2
PCB1
D7003 or C-DIODE 1SS355 ( 1) 223269R2
PCB1
D7004 C-DIODE 1SS352 1 223234R2
PCB1
D7004 or C-DIODE 1SS355 ( 1) 223269R2
PCB1
D7702 ZENER D UDZS6.2B 1 224550620R2
PCB1
D7702 or ZENER D UDZ6.2B ( 1) 224490620R2
PCB1
D7702 or ZENER D HZU6.2B ( 1) 224660624R2
