Onkyo HT-R320 Service Manual

13/30 PAGE
PCB1
P301 PIN JACK NPJ-6PDRW386 1 25045571
PCB1
P301 or JACK NPJ-6PDBL159 ( 1) 25045300
PCB1
P301 or PIN JACK NPJ-6PDWWWRRR561 ( 1) 25045779
PCB1
P302 JACK NPJ-2PDBL185 1 25045333
PCB1
P302 or PIN JACK NPJ-2PDWR558 ( 1) 25045776
PCB1
P304 PIN JACK NPJ-6PDRW386 1 25045571
PCB1
P304 or JACK NPJ-6PDBL159 ( 1) 25045300
PCB1
P304 or PIN JACK NPJ-6PDWWWRRR561 ( 1) 25045779
PCB1
P305 PIN JACK NPJ-6PWRLGGP493 1 25045697
PCB1
P305 or PIN JACK NPJ-6PDWLGREP562 ( 1) 25045780
PCB1
P306 SOCKET AS NSAS-20P1004 1 2009990717UL
PCB1
P351 PIN JACK NPJ-1PDP510 1 25045720
PCB1
P351 or PIN JACK NPJ-1PDP555 ( 1) 25045773
PCB1
P410B PLUG NPLG-10P662 1 25055706
PCB1
P411B PLUG NPLG-10P662 1 25055706
PCB1
P412B PLUG NPLG-8P660 1 25055704
PCB1
P6403 RETAINER KANAGU 1 27141059
PCB1
P7502B SOCKET NSCT-10P2473 1 25052576R2
PCB1
P801 PLUG NPLG-14P666 1 25055710
PCB1
E300 RETAINER KANAGU 1 27141059
U2
DISPLAY PC BOARD (NADIS-7403-3B)
U3
SWITCH PC BOARD (NASW-7404-3B)
U4
HEADPHONE JACK PC BOARD (NAETC-7405-3B)
<Note> The parts of each PC board are indicated collectively.
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
PCB2
U7501 REMO SENS SPS-444-1-VP 1 241352
PCB2
Q7501 FL TUBE 16BT123GK 1 212250
PCB2
Q7501A HOLDER (FL) 1 27190989B
PCB2
Q7502 IC MPD780232GC-030-8BT 1 22241571R3
PCB2
Q7503 TR KTC3875-GR 1 2216175R2
PCB2
Q7503 or TR 2SC2712-GR ( 1) 2213145R2
PCB2
Q7504 TR KRA103S 1 2216230R2
PCB2
Q7504 or TR RN2403 ( 1) 2214540R2
PCB2
Q7506 TR KRC102S 1 2216190R2
PCB2
Q7506 or TR RN1402 ( 1) 2214470R2
PCB2
D7501 ZENER D UDZS8.2B 1 224550820R2
PCB2
D7501 or ZENER D UDZ8.2B ( 1) 224490820R2
PCB2
D7501 or ZENER D HZU8.2B ( 1) 224660824R2
PCB2
D7502 ZENER D UDZS5.1B 1 224550510R2
PCB2
D7502 or ZENER D UDZ5.1B ( 1) 224490510R2
PCB2
D7502 or ZENER D HZU5.1B ( 1) 224660514R2
PCB2
D7503 C-DIODE 1SS355 1 223269R2
PCB2
D7503 or C-DIODE 1SS352 ( 1) 223234R2
PCB2
D7505 LED SLR-56VRTB7 1 225431
PCB2
D7505 or LED SEL4110R ( 1) 225290
PCB2
D7507 C-DIODE 1SS355 1 223269R2
PCB2
D7507 or C-DIODE 1SS352 ( 1) 223234R2
PCB2
L7504 CHOKE COIL NCH-1477 1 231237K220R2
PCB2
L7505 CHOKE COIL NCH-1477 1 231237K220R2
PCB2
X7501 CERA LOCK CST5.00MGW 1 3010242
PCB2
C7501 C-CERA C CK725F1E-104Z1 1 332161040R1
PCB2
C7502 ELECT C CE04W50V-33M 1 355783309
PCB2
C7503 C-CERA C CK725F1E-104Z1 1 332161040R1
