HT-R320
EXPLODED VIEWS-2
HT-R320
Q6064
Q6063
Q6062
Q6061
Q6060
Q6050
Q6051
Q6052
Q6054
Q6053
Q6050A
x10
A037
x10
A416
(L=85mm)
A417
(L=160mm)
<Fig-2><Fig-1>
FRONT PANEL INSIDE VIEW
A416
(L=85mm)
A415
(L=135mm)
A418
(L=215mm)
