Onkyo HT-R380 Service Manual

Q6012 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q6013 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q6014 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q6017 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q6021 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q6022 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q6023 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q6024 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q6051 TR KRC105S 1 2217290R2
Q6051 or TR RN1405 ( 1) 2214500R2
Q6051 or TR DTC123JKA ( 1) 2216690R2
Q6052 TR KRC105S 1 2217290R2
Q6052 or TR RN1405 ( 1) 2214500R2
Q6052 or TR DTC123JKA ( 1) 2216690R2
Q6053 TR KRC105S 1 2217290R2
Q6053 or TR RN1405 ( 1) 2214500R2
Q6053 or TR DTC123JKA ( 1) 2216690R2
Q6055 TR KRC105S 1 2217290R2
Q6055 or TR RN1405 ( 1) 2214500R2
Q6055 or TR DTC123JKA ( 1) 2216690R2
Q6057 TR KRC105S 1 2217290R2
Q6057 or TR RN1405 ( 1) 2214500R2
Q6057 or TR DTC123JKA ( 1) 2216690R2
Q6380 IC LM61CIZ 1 22242212
Q6380A RETAINER (PTH) 1 27141884-1
Q6707 TR KTC3875-GR 1 2216175R2
Q6707 or TR 2SC2712-GR ( 1)
2213145R2
Q960 TR 2SC2235-Y(TPE6_F) 1 2211654T
Q960 or TR 2SC2235-O(TPE6_F) ( 1) 2211653T
[TRANS COIL]
L4001 CHOKE COIL LBC2518T2R2M 1 231364M022R2
L6000 S COIL SC-0.8X6.0X29.5T-4RV-C 1 231394AS
L6000 or S COIL PB9510 ( 1) 231361
L6001 S COIL SC-0.8X6.0X29.5T-4RV-C 1 231394AS
L6001 or S COIL PB9510 ( 1) 231361
L6002 S COIL SC-0.8X6.0X29.5T-4RV-C 1 231394AS
L6002 or S COIL PB9510 ( 1) 231361
L6003 S COIL SC-0.8X6.0X29.5T-4RV-C 1 231394AS
L6003 or S COIL PB9510 ( 1) 231361
L6004 S COIL SC-0.8X6.0X29.5T-4RV-C 1 231394AS
L6004 or S COIL PB9510 ( 1) 231361
L6007 S COIL SC-0.8X6.0X29.5T-4RV-C 1 231394AS

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
