Onkyo HT-R380 Service Manual

L6007 or S COIL PB9510 ( 1) 231361
[CAPACITOR]
C4001 C-CERA C CC725CH1H-152J1 1 NSP
C4002 C-CERA C CC725CH1H-152J1 1 NSP
C4003 UPZ C 2AUPZTF221JE 1 376332214T
C4004 UPZ C 2AUPZTF221JE 1 376332214T
C4007 C-CERA C CC725CH1H-221J1 1 NSP
C4008 C-CERA C CC725CH1H-221J1 1 NSP
C4013 C-CERA C CC725CH1H-221J1 1 NSP
C4014 C-CERA C CC725CH1H-221J1 1 NSP
C4017 C-CERA C CC725CH1H-221J1 1 NSP
C4018 C-CERA C CC725CH1H-221J1 1 NSP
C4019 UPZ C 2AUPZTF221JE 1 376332214T
C4020 UPZ C 2AUPZTF221JE 1 376332214T
C4050 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4051 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4052 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4053 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4054 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4057 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4060 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4061 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4062 TF C ECQ-V50V-474J 1 374724744T
C4063 TF C ECQ-V50V-823J 1 374728234T
C4064 TF C ECQ-V50V-223J 1 374722234T
C4065 TF C ECQ-V50V-474J 1 374724744T
C4066 TF C ECQ-V50V-823J 1 374728234T
C4067 TF C ECQ-V50V-223J
1 374722234T
C4070 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4071 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4072 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4073 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4074 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4077 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4085 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4086 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4090 C-CERA C CC725CH1H-101J1 1 342101014R1
C4091 C-CERA C CC725CH1H-101J1 1 342101014R1
C4100 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4101 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4102 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4103 UTSP C CE04W50V 47M(UTSP) 1 397584707T

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
