Onkyo HT-R380 Service Manual

C4104 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4107 UTSP C CE04W50V-2.2M(UTSP) 1 397580227T
C4130 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C4131 C-CERA C CC725CH1H-221J1 1 342102214R1
C4132 TF C ECQ-V50V-103J 1 374721034T
C4166 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C4167 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C4170 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C4171 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C4172 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C4173 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C4186 UTSP C CE04W16V-470M(UTSP) 1 397544717T
C4187 UTSP C CE04W16V-470M(UTSP) 1 397544717T
C4203 C-CERA C CC725CH1H-102J1 1 342101024R1
C4204 C-CERA C CC725CH1H-102J1 1 342101024R1
C4205 C-CERA C CC725CH1H-102J1 1 342101024R1
C4209 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4210 UTSP C CE04W25V-47M(UTSP) 1 397554707T
C4300 TF C ECQ-V50V-334J 1 374723344T
C4301 VR C CE04W35V-1000M(VR) 1 394661027S
C4302 VR C CE04W35V-470M(VR) 1 394664717T
C6009 TF C ECQ-V50V-333J 1 374723334T
C6010 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C6011 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C6012 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C6013 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C6014 UTSP C CE04W50V 47M(UTSP) 1
397584707T
C6017 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C6020 UPZ C 2AUPZTF471JE 1 376334714T
C6021 UPZ C 2AUPZTF471JE 1 376334714T
C6022 UPZ C 2AUPZTF471JE 1 376334714T
C6023 UPZ C 2AUPZTF471JE 1 376334714T
C6024 UPZ C 2AUPZTF471JE 1 376334714T
C6027 UPZ C 2AUPZTF471JE 1 376334714T
C6030 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C6031 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C6032 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C6033 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C6034 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C6037 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C6040 CERA C CC45CH50V-030D 1 345340302T
C6041 CERA C CC45CH50V-030D 1 345340302T

Onkyo HT-R380 Specifications

General

Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Weight	17.6 lbs
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Surround System Class	5.1 channel
Digital Sound Processor (DSP)	Yes
HDMI Switching	Yes
Bluetooth	No
HDMI Version	1.4a
Power Output	100W per channel (6 ohms, 1 kHz, 1% THD, 1 channel driven)
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio
DSP Presets	Game, Movie, Music
Input Video Formats	HDMI
Audio D/A Converter	24bit / 192kHz
Inputs	HDMI, Composite, Optical, Coaxial
Outputs	HDMI, Composite
